Category: Industrial Valve Series
Description:
Technical Standard Design Standard：GB/T12235、ASMEB16.34、BS1873、JISB2071
Pressure-Temperature Rating:GB/T12224、ASME B 16.34
Face To Face Std：GB/T12221、ASMEI B 16.10、BS4460、DIN2202
End Flanged Std:GB9113、JB79、ASME B 16.5a、DIN2543-2546、BS4504、JISB2213-2216
Test Standard:GB/T13927、ISO5208、API598
Material：WCB、CF8(304)、CF8M(316)
Operated Way:Handle、Gearcase、Electric
| Follow Us: |  |
 |
 |
 |
 |
Flanged Globe Valve
| Size Range | DN | 50-200mm | |
| Working Pressure | DN | 1.6-6.4Mpa、150-300LB、10K、20K | |
| Suitable Temperature | SS:（-29-200°C） WCB（-29-425°C） | ||
| Suitable Medium | CF8304：Nitric acid | CF8M316：Acetic acid | Water、Natural gas、Oil |
