Category: Industrial Valve Series
Description:
Technical Standard Design Standard：GB/T12224、GB/T8464
Pressure-Temperature Rating:GB/T12224
Face To Face Std：GB/T8464
End Connection Std:G、Rc、Rp、NPT、BSP、BSPT、DIN259/2999
Test Standard:GB/T13927
Material：CF8(304)、CF8M(316)
| Follow Us: |  |
 |
 |
 |
 |
Threaded Swing Check Valve
DIMENSIONS
| Item Size | 1/2" | 3/4" | 1" | 11/4" | 11/2" | 2" | 21/2" | 3" |
| D | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 |
| L | 65 | 80 | 90 | 105 | 120 | 140 | 180 | 200 |
| H | 42 | 51 | 60 | 64 | 75 | 81 | 93 | 104 |
| Size Range | DN | 10-50mm | |
| Working Pressure | DN | 2.5Mpa | |
| Suitable Temperature | WCB（-29-200°C） | ||
| Suitable Medium | CF8304：Nitric acid | CF8M316：Acetic acid | Water、Natural gas、Oil |
