Category: Industrial Valve Series
Description:
Technical Standard
Type:Q11F
Design Standard：GB/T12224、GB/T8464
Pressure-Temperature Rating:GB/T12224
Face To Face Std：GB/T15188.3
End Connection Std:G、Rc、Rp、NPT、BSP、BSPT、DIN259/2999
Test Standard:GB/T13927
Material：WCB、CF8(304)、CF8M(316)
Operated Way:Handle、Actuator、Electric
| Follow Us: |  |
 |
 |
 |
 |
2PC Ready-package Ball Valve
DIMENSIONS
| Item Size | 1/2" | 3/4" | 1" | 11/4" | 11/2" | 2" |
| D | 15 | 20 | 25 | 32 | 38 | 50 |
| L | 92 | 104 | 121 | 138 | 149 | 171 |
| H | 60 | 64 | 71 | 78 | 86 | 95 |
|
E |
103 | 117 | 148 | 160 | 95 |
182 |
| Size Range | DN | 6-100mm | |
| Working Pressure | DN | 1.6-6.4Mpa | |
| Suitable Temperature | （-29-200°C） | ||
| Suitable Medium | CF8304：Nitric acid | CF8M316：Acetic acid | Water、Natural gas、Oil |
